INVERTER DC TIG / MMA WELDING MACHINE

Your location：Home >> INVERTER DC TIG / MMA WELDING MACHINE

Product Name：INVERTER DC TIG / MMA WELDING MACHINE

Product Model：TIG315I

Product Brief：TIG/MMA 2 in 1. Portable with light weight in shop or at job site . Easy arc-striping and stable current, fast dynamic reaction .

Back >>

Feedback Form:

E-mail：	*
Message：	*

TIG/MMA 2 in 1. Portable with light weight in shop or at job site .

Easy arc-striping and stable current, fast dynamic reaction .

Compatible with network or generator use .

Auto protection against over voltage and over hea

Back >>

Model	TIG315I
	MMA	TIG
Input power voltage（V）	AC380V+15% 3PH
Rated input power capacity	20	13.7
No-load voltage(V)	67
Output current range(A)	20-315	20-315
Rated output voltage	32.6	22.6
Arc force adjustment(A)	0-100
Duty cycle(%)	60
No-load consumption	60
Efficiency（%）	85
Power factor	0.93
Insulation class	F
Protection class	IP21S
Weight(KG)	14.5
Diamension(mm)	450220345
