INVERTER DC PULSE TIG/MMA WELDING MACHINE
Your location：Home >> INVERTER DC PULSE TIG/MMA WELDING MACHINE
Product Name：INVERTER DC PULSE TIG/MMA WELDING MACHINE
Product Model：TIG200P
Product Brief：Portable with light weight in shop or at job site.
Two welding modes, TIG and MMA.
Easy arc-striking and stable current, fast dynamic reaction.
Portable with light weight in shop or at job site. Two welding modes, TIG and MMA. Easy arc-striking and stable current, fast dynamic reaction. Outstanding arc stability and welding performance with pulse function. Speedy up slope pulse current and down slope pulse current, excellent effect in thin metal sheet welding, especially applicable for vacuum container and bicycle industry. Compatible with network or generator use. Auto-protection against over voltage and over heat.
Model
TIG200A
MMA
TIG
Input power voltage（V）
AC220V+15%,1PH
Rated input power capacity（KVA）
6.4
4.1
Rated input current(A)
29.1
18.5
No-load voltage（V）
56
Output current range（A）
10-185
10-185
Rated output voltage （V）
27.4
17.4
Post-gas （S）
2+0.5
Pre-flow time (S)
0-2
Pulse current(A)
10-200
Slope-down time (S)
0-5
Pulse frequency(HZ)
1-70
Pulse width(%)
10-90
Duty cycle（%）
60
Weight（KG）
13
Dimension（mm
356*153*225
Metal workshops Repair and maintenance Installation and set-up Thin sheet metal fabrication workshops Chemical and process industry
